Plot camera trap activity over time

mm_plot_camtrap_activity.Rd

Visualizes the activity history of camera trap deployments to show periods of data capture. It also optionally highlights periods of inactivity (break/gap).

Usage

mm_plot_camtrap_activity(
  data,
  deployment,
  datetime,
  threshold = 5,
  time_unit = "days",
  format = NULL,
  activity_style = list(width = 0.8, color = "steelblue", alpha = 0.7),
  break_style = list(width = 0.8, color = "#c90026", alpha = 0.9),
  show_gaps = TRUE,
  ylabel_format = "%Y-%m-%d",
  ybreak = paste(1, time_unit)
)

Arguments

data

A data frame containing the datetime column.

deployment

Column name (unquoted) that identifies the deployment or camera ID.

datetime

The datetime column.

threshold

A numeric value indicating the minimum gap to be considered a break (default is 10).

time_unit

The unit for the threshold. Supported values include "secs", "mins", "hours", "days", and "weeks".

format

Optional. A character string specifying the datetime format, passed to as.POSIXlt.

activity_style

A list controlling the appearance of active periods. Can include:

  • width: Line width (default 0.8)

  • color: Color of activity bars (default "steelblue")

  • alpha: Transparency (default 0.7)

break_style

A list controlling the appearance of gaps/inactive periods. Can include:

  • width: Line width (default 0.8)

  • color: Color of gap bars (default "#c90026")

  • alpha: Transparency (default 0.9)

show_gaps

Logical. If TRUE (default), shows vertical bars for detected gaps in deployment activity.

ylabel_format

Character. Format for y-axis date-time labels. Default is "%Y-%m-%d".

ybreak

Character. Spacing for y-axis breaks, e.g., "1 days" or "12 hours". Default is based on time_unit.

Value

A ggplot2 object showing periods of activity (and optionally gaps) for each deployment.

Examples

# Load example data and filter for one project
camtrap_data <- read.csv(maimer:::table_files()[1]) %>%
  dplyr::filter(project == "Last")

# Plot with default styles
mm_plot_camtrap_activity(
  data = camtrap_data,
  deployment = camera,
  datetime = datetimes,
  threshold = 7,
  time_unit = "days"
)


#' # Customize plot appearance
mm_plot_camtrap_activity(
  data = camtrap_data,
  deployment = camera,
  datetime = "datetimes",
  threshold = 15,
  time_unit = "days",
  ybreak = "3 days",
  activity_style = list(width = 1.1, color = "gray10")
)+
  ggplot2::theme(axis.text.x = ggplot2::element_text(angle = 45, hjust = 1))

#'
